Vertical Lift Cold Storage Door

 Vertical Lift Cold Storage Door

Haocool not only focuses on the design and installation of cold storage systems, but also provides customers with recommendations for choosing relevant products used in refrigeration engineering, a full set of program designs, procurement assistance, installation, commissioning, and integrated turnkey project services.

The vertical lift cold storage door is resistant to 110km / h wind. Doors such as this are safe and reliable with steady opening, low noise, good sealing, and temperature insulation. Vertical lift cold storage doors are suitable for the cold storage of medicine, food, electronics, supermarkets and other applications with high sanitary and temperature requirements. The thickness of the vertical lift door is 40-50mm. It is made of double-sided color plate and high-density polyurethane foam material. Each vertical lift cold storage door can be configured with different devices according to customers’ needs.

Specification
Vertical Lift Door
Door material Double hot galvanized embossed steel plate
Core material Polyurethane
Color White, almond, brown
Door size Width: 2440-12000mm Height: 2130-15000mmThickness: 40mm
Thermal resistance R=14.96, 18.25
Sealing performance Bottom U-shaped vinyl seal is freeze resistant and waterproof. The side and top of the door are sealed with a slot seal. The joints between the doors are sealed with convex or concave groove and thermal isolation tube or strip seal.
Access door When the width of the door is less than 5500mm, you can choose an access door with different sizes according to your needs. .
Inspection window You can choose inspection windows of different sizes at your request.
Wind resistance 110Km / h - equivalent to storm.
